W 45 Casement

Specification

Profile Alloy 6063
Glass Thickness 05mm to 20mm
Max Width/Shutter 900mm
Max Height/Shutter 2400mm
Max Weight/Shutter 60 kgs
Single/Multi Locking Yes
Mosquito Mesh Solution Yes
Hinge Butt/Friction
Opening Side Hung/Top Hung
Frame Height 48 mm
Frame Width 45 mm
Shutter 45mm X 65mm
Mullion Sightline with Shutter 165mm
